    EVA Foaming Vulcanizing Press, Rubber Machine, Foaming Sheet Rubber Press, EVA Foaming

    Ask Lasest Price
    Brand Name : SFC
    Model Number : XLB-1200X1200X4
    Certification : CE, ISO
    Price : US$10,000.00-5000.00
    Payment Terms : T/T,L/C
    Supply Ability : 900 set/year
    Delivery Time : 25-35 days
    • Product Details
    • Company Profile

    EVA Foaming Vulcanizing Press, Rubber Machine, Foaming Sheet Rubber Press, EVA Foaming

    EVA Foaming Vulcanizing Press with 1200x1200mm Platen Size
    Professional rubber processing equipment for EVA foam production with automatic operation and CE/ISO9001:2008 certification.
    Technical Specifications
    Model: XLB-1200X1200X4
    Total Pressure: 5MN
    Motor Power: 18.5KW
    Platen Size: 1200*1200mm
    Daylight: 150mm
    Automation: Automatic
    Certification: CE, ISO9001:2008
    EVA Foaming Vulcanizing Press - Industrial rubber processing machine
    Key Features
    • High quality plate press with beautiful modeling and compact structure
    • High speed open/close mold for increased production efficiency
    • Simple structure with wide application range and easy operation
    • Available with hand control or electric control systems
    • Small temperature difference and reliable pressure performance
    • Automatic pressure compensation during curing process
    • Low operation height designed for ergonomic use
    • Rapid mold opening with toggle mechanism
    • Energy saving design with space-saving configuration
    Applications
    This machine is primarily used for manufacturing EVA foam products including: slippers, foam sheets, insulation materials, sports protective gear, life jackets, sponges, mid-soles, rainboots, sandals, clogs, and various shoe accessories.
    Technical Parameters
    Parameter/TypeXLB-Q 1200x1200x4XLB-Q 1400x1500x6XLB-Q 1500x1500x6
    Total Pressure (MN)5.08.010.0
    Plate Size (mm)1200*12001400*15001500*1500
    Plate Clearance (mm)150150150
    Piston Stroke (mm)500800150
    Plate Unit Pressure (Mpa)3.43.84.5
    Main Motor Power (KW)18.52633
    Dimension (mm)2400*2100*32002650*2400*36002750*2400*3600
    Weight (kg)220003800048000
    EVA Foaming Vulcanizing Press technical details and components
    Operational Notes
    • Clamping force adjustable from 150 to 210 tons based on requirements
    • Fully hydraulic automatic operation with PLC control system
    • Humanized parameter computer interface for precise production control
    • Available for 2-plate molds with thickness adjustment scope: 100-200mm
    • No water circulation required for mold station
    Contact Information
    WhatsApp: +8618344700139
    Email: rubbermachine@sfcjx.com
    Origin: Jiaonan, Qingdao, China
    Production Capacity: 200 Sets/Year
    Qingdao Shun Cheong Machinery Co., Ltd provides first-class technology, quality service, and cost-effective rubber processing equipment for domestic and international customers.
